INPUT VOLTAGES |
OTHER FUNCTION |
||
|
200V~240V AC，50/60Hz |
Adjustable Pan & Tilt speed | ||
|
Lamp and Total hours displayed |
|||
|
INPUT POWER |
Touch screen English and Chinese Display with |
||
|
1800W@220V |
Contrast and brightness adjustable |
||
|
Power factor: PF>0.95 |
Energy saving ballast |
||
|
|
Built-in sensor diagnostic system |
||
|
Input signal isolation |
|||
|
LIGHT SOURCE |
Modular Structure for easy maintenance |
||
|
OSRAM lok-it 1400/PS (6000K,CRI >90,single ended ,750hrs) |
Ethernet Interface |
||
|
DMX512 wireless reciever |
|||
|
CTO |
DMX512 Transmitter ( Optional) |
||
|
0-100% linear CTO |
ArtNet and sACN ( Optional) |
||
|
ZOOM |
HOUSING |
||
|
DMX linear zoom |
High temperature ABS, IP20 |
||
|
DIMMER |
NET WEIGHT |
||
|
0-100% linear dimmer |
44Kg |
||
|
STROBE |
PACKAGING |
||
|
Double shutter blades, 0.3~25 F.P.S |
Standard: carton 840x640x738(mm) |
||
|
Optional: flight case 720x580x900(mm) |
|||
|
HEAD MOVEMENT |
|||
|
Pan 540º, Tilt 270º with auto position correction |
OPERATION TEMPERATURE |
||
|
Ambient temperature at maximum：40°C |
|||
|
BEAM ANGLE |
|||
|
Linear zoom 10°～ 60°with 16 bit function |
ACCESSORIES |
||
|
Clamps 2 Pcs |
|||
| CONTROL |
XLR Connector 1 Set Male and female |
||
| DMX512, 5 pin interfaces |
Safety cord 2 Pc |
||
| RDM control protocol |
User manual 1 Pc |
||
|
18channels in short mode, 23channels in standard mode and 27channels in extended mode |
|||
|
Self-test mode |
|||
|
|
|||
| 【Version：20230612】 | |||
| CMY | |||
|
CMY linear mixing system with macros |
|||
| Color Wheel | |||
|
2color wheels: 7colors+ Open，Half Color effect |
|||
| Rainbow effect with bi-directional and variable speeds
|
|||
| Stepping/linear color changing | |||
