Input voltage |
Strobe |
||
|
100V-240V AC,50/60Hz |
Electronic strobe, 0.3~25 F.P.S |
||
| Input power |
Head movement |
||
|
1450W@220V |
Pan 540º, Tilt 270º with auto position correction and 16 bit control |
||
|
1600W@100V |
|
||
| Control | |||
|
Light sources |
International standard DMX512 signal and RDM function | ||
|
1000W white LED module,6900K |
38channels in short mode, 42channels in standard mode,57channel in extended mode |
||
| Ra≥95, R9≥95 ( Optional highly bright version: Ra≥70) |
|
||
|
Manufacturers Rated Lamp Life:>20000hrs |
Control interface | ||
| DMX512 ports（5-pin) | |||
|
Cto |
Ethernet port RJ45 |
||
|
Linear CTO system(0-100%, 1800K-6500K) |
|
||
|
Other functions |
|||
|
Effect wheel |
Pan and Tilt speeds adjustable |
||
|
1 animation effect wheel, bi-directional rotation with varied speeds |
Pan and Tilt swappable and invertible |
||
|
High precision magnet sensor for positioning |
|||
|
Iris |
3.2-inch touch color screen, Chinese and English menus, |
||
|
Linear iris 5-100% with macros |
Screen automatic lock –up while standby |
||
|
Error diagnostic system with sensors |
|||
|
Prism |
Smart fan cooling system |
||
|
1 pc of 4-facet circular prism, bi-directional rotation with varied speeds with indexing function |
Display of fixture hours and software versions |
||
|
Modular construction for easy maintenance |
|||
|
Frost |
Isolated input signals |
||
|
1 heavy frost filter (0-100% linear) |
Firmware update via DMX cable or USB port |
||
|
DMX512 wireless reciever |
|||
|
Beam angle |
DMX512 Transmitter(Optional) | ||
|
Linear zoom 6°～ 54° with 16 bit precision |
ArtNet and sACN(Optional) |
||
|
Focus |
IP Rating | ||
|
Linear focus with auto-focus function |
IP20 |
||
|
Dimmer |
Operation temperature |
||
|
Linear electronic dimmer 0-100% with 16 bit control |
Ambient temperature 45℃ at maximum |
||
|
3 dimmer speeds |
|||
|
4 dimmer gamma curves |
Weight | ||
|
Dimmer frequency adjustable between 1.2K and 25K |
Net weight 45Kg | ||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| Color Wheel | |||
|
1 Color Wheels: 6 colors+Open |
|||
| Color Wheel: Red, Green, Blue, Orange, Pink, Light cyan, Open | |||
| Bi-directional rainbow effect with variable speeds | |||
|
Full color/half color/linear color |
|||
| Rotating Gobo | |||
|
1 rotating gobo wheel: 6 exchangeable+ open |
|||
|
Bi-directional rotation, indexing, shake with varied speeds |
|||
|
bi-directional scrolling with varied speeds |
|||
| Fixed Gobo | |||
|
1 Fixed gobo wheel: 7 exchangeable gobos+ open |
|||
|
Shake effect with varied speeds and bi-directional rotation with varied speeds |
|||
| Framing | |||
|
Framing module:4 framing blades to make graphics with different sizes and shapes |
|||
| Each blade to make full curtain effect .Continual and bi-directional rotation for the whole module | |||
