| ELECTRICAL PARAMETERS Input voltage: 200V-240V AC，50/60Hz Input power: 1950W@220V Maximum Current: 9A @220V Power factor: PF>0.95 SPECIFICATIONS OF LIGHT SOURCE Lamp：1800W ,LED white Colour Temperature：8000K Manufacturers Rated Lamp Life：＞20000hrs CRI：Ra ≥70 Optional high CRI light source：Ra ≥95, R9 ≥95 CTO Linear CTO system(0-100%),（1800K-6500K） EFFECT WHEEL 1 animation effect wheel, bi-directional rotation with varied speeds IRIS Linear iris 5-100% with macros PRISM 1pc of 4-facet circular prism, bi-directional rotation with varied speeds with indexing function FROST 2frost filter, 1 heavy frost+1 light frost ， ( 0-100% linear ) BEAM ANGLE Linear zoom 5°-56°with 16 bit precision FOCUS DMX linear focus DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds 5 dimmer gamma curves Dimmer frequency(1.2K-25K) STROBE Electronic strobe, 0.3~25 F.P.S with options for synchronous and asynchronous random strobes HEAD MOVEMENT Tilt ：270º |
ADVANCE MACROS Color temperature macros ：2700K、3000K、3500K、4000K、4500K、5000K、5700K Color macros ：89colors FAN MODE Standard mode and theatre mode. Theatre mode is quiet mode. BRIGHTNESS CALIBRATION Brightness calibration function to calibrate initial brightness of a fixture or some fixtures in a DMX chain and store the brightness value in the fixture/fixures. CRI MODE For high CRI version fixtures, activation of high CRI mode by control channel for high CRI beam while dimming CONTROL International standard DMX512 signal with 5-pin DMX512 interfaces,RDM protocol ArtNet protocol(optional) 35channels in short mode, 40channels in standard mode,54channel in extended mode Master/Salve synchronized control mode Standalone mode INTERFACE DMX 512 connector(5-pin, optional 3-pin) and Ethernet connectorRJ45(optional) OTHER FUNCTIONS Display of fixture and lamp hours, and software versions Smart fan cooling system Error diagnostic system with sensors Isolated input signals Modular construction for easy maintenance Firmware update via DMX cable DMX wireless receiver HOUSING AND INGRESSION PROTECTION High tensile cast aluminum + high temperature Engineering plastics, IP66 WORKING TEMPERATURE Working temperature 45℃ at maximum Note: if the ambient temperature is below -20℃, reset it after preheating it more than 30 min WEIGHT Net weight 50KG |
| 【Version:20260825】 |
