| ELECTRICAL PARAMETERS Input voltage：200V-240V AC，50/60Hz Input power： 2100W@220V Maximum Current ：9.5A @ 220V Power factor： PF>0.95 SPECIFICATIONS OF LIGHT SOURCE Lamp：1800W ,LED white Colour Temperature：8000K Manufacturers Rated Lamp Life：20000hrs CRI：Ra ≥70 Optional high CRI light source：Ra ≥95, R9 ≥95 CTO Linear CTO system(0-100%),（1800K-6500K） FRAMING Framing module：4 framing blades to make graphics with different sizes and shapes,each blade to make full curtain effect Bi-directional continual rotation for the whole module EFFECT WHEEL 1 animation effect wheel, bi-directional rotation with varied speeds IRIS Linear iris 5-100% with macros PRISM 1pc of 4-facet circular prism, bi-directional rotation with varied speeds with indexing function FROST 2frost filter, 1 heavy frost+1 light frost ， ( 0-100% linear ) BEAM ANGLE Linear zoom 5°～ 56°with 16 bit precision FOCUS DMX linear focus DIMMER Linear electronic dimmer 0-100% with 16 bit control 3 dimmer speeds 5 dimmer gamma curves Dimmer frequency(1.2K-25K) STROBE Electronic strobe, 0.3~25 Hz with options for synchronous and asynchronous random strobes |
HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction and 16 bit control ADVANCE MACROS Color temperature macros ：2700K、3000K、3500K、4000K、4500K、5000K、5700K Color macros ：89colors included in standard LEE color chart FAN MODE Standard mode and theatre mode. Theatre mode is quiet mode. BRIGHTNESS CALIBRATION Brightness calibration function to calibrate initial brightness of a fixture or some fixtures in a DMX chain and store the brightness value in the fixture/fixures. CRI MODE For high CRI version fixtures, activation of high CRI mode by control channel for high CRI beam while dimming CONTROL International standard DMX512 signal with 5-pin DMX512 interfaces RDM protocol ArtNet protocol(optional) 40channels in short mode, 45channels in standard mode,59channel in extended mode Master/Salve synchronized control mode Standalone mode OTHER FUNCTIONS Pan and Tilt speeds adjustable Pan and Tilt swappable and invertible Touch color screen, Chinese and English menus, brightness and contrast adjustable Smart fan cooling system Error diagnostic system with sensors Display of fixture hours and software versions Modular construction for easy maintenance Monitoring the voltages of DMX channels Positioning by Highly precise magnet sensor, signal feedback, absolute position memory and auto position correction after power off or DMX offline. Isolated input signals ArtNet interfaces(optional) DMX wireless receiver DMX wireless transmitter(optional) HOUSING AND INGRESSION PROTECTION High tensile cast aluminum + high temperature ABS, IP66 WORKING TEMPERATURE Working temperature 45℃ at maximum Note： if the ambient temperature is below -20℃, reset it after preheating it more than 30 min WEIGHT Net weight 49 Kg |
| 【Version：20250804】 |
