| ELECTRIC PARAMETERS Input voltage：200V~240V AC，50/60Hz Input power：500W@230V Power factor：PF>0.90 THE SPECIFICATIONS OF THE LIGHT SOURCE Lamp：MSD Platinum 300S Flex Color temperature：7800K+/-300K rated life ：6000hrs EFFECT WHEEL 1 fire effect wheel PRISM/FROST 1 8-facet prism and 1 16-facet prism, bi-directional rotation from slow to fast FOCUS DMX linear focus DIMMER /STROBE Strobe at variable speeds(15 F.P.S at maximum) 0-100% linear dimmer HEAD MOVEMENT Pan 540º, Tilt 270º with 16 bit control BEAM ANGLE Beam: 2°～ 20° Spot: 6°～ 30° Wash: 17°～ 45° |
CONTROL Projector and lamp information readable, external DMX value received and thermal sensor built-in for error and malfunction analysis Preset memory Unintentional head move to cause power-off, quiet fans for cooling International standard DMX 512 protocol, 5-pin interface 19channels in short mode and 23channels in standard mode OPTIONAL WIRELESS CONTROL MODULE/RDM MODULE Compliant with USITT DMX-512（1986 and 1990）and 512-A Full DMX for fidelity and DMX framing integrity Auto-detecting DMX framing size and speed <5ms DMX delay Frequency range 2402-2480 MHz HOUSING High temperature ABS and aluminum , IP20 NET WEIGHT 19Kg OPERATION TEMPERATURE Ambient temperature at maximum：40°C |
