| Electric parameters Input voltage: 100V~240VAC，50/60Hz Power consumption:660W @220V Rated current:3.0A/220V Power factor:PF>0.9 Light sources Light sources：500Wlaser module Color temperature：9500K Rated life：12000hrs Prism 2 prism wheels: 1 wheel (an 8-facet circular prism+a 4-facet linear prism )+1 wheel (a 9-facet circular prism +a gradient prism), prisms can be overlapped.Other prism options available Frost 1 pc frost filter Focus DMX linear focus Strobe/Dimmer Double flag strobe，0.3-25 F.P.S./linear dimmer Movements Pan (0°-540°)，Tilt(0°-270°)with auto positioning correction function |
Beam angle Beam/Spot mode angle：0.8°-26° Wash mode : 1.8°-30° Unique super wide angle/under wash mode :38°-60° Control International standard DMX 512 signal ,5-pin XLR connectors Short Mode 23 channels，standard Mode 28 channels,extended mode 31 channels Self test mode Other functions Pan and Tilt speeds adjustable Lamp hours and fixture hours displayed Modular construction easy for maintenance Wireless receiver Wireless transmitter (Optional) ArtNet control(Optional) Housing and ingress protection Cast aluminum and high temperature and UV resistantABS with IP66 Weight Net weight：37.8Kg Ambient temperature 45 °C at maximum Note: If the ambient temperature is below 0°C,preheat the fixture for some time( less than 20 min based on actual situation normally)before striking the light source |
| 【Version:20260319】 |
