Input Voltage |
Control |
||
|
100V-240V AC，50/60Hz |
International standard DMX512 signal , 5 pin interface(Optional 3pin interface) |
||
|
RDM control protocol |
|||
|
Input Power |
ArtNet protocol(Optional) |
||
|
950W@220V AC |
35channels in short mode, 38channels in standard mode,54channel in extended mode |
||
|
980W@100V AC |
Master/slave synchronized mode |
||
|
Power factor: PF>0.95 |
Stand-alone mode |
||
|
Light Source |
Other Functions |
||
|
Lamp 600W ,LED white (8000K, 20000hrs) |
Adjustable Pan & Tilt speeds |
||
| Ra≥70 |
Pan and Tilt swappable and invertible |
||
|
Ra≥95 , R9≥90 (Optional) |
Fixture and lamp hours’ display |
||
|
|
Color screen, Chinese-English menus, brightness and contrast adjustable |
||
|
Diagnostic system with sensors |
|||
|
CTO |
Software version display |
||
|
Linear CTO system(0-100%) |
Protection and insulation of input signals |
||
|
Modular construction for easy maintenance |
|||
|
Prism |
ArtNet interface(Optional) |
||
|
1pc 4 facet prism, bi-directional rotation with varied speeds and indexing function |
DMX512 wireless receiver |
||
|
DMX512 wireless transmitter (optional) |
|||
|
Frost |
|||
|
Linear frost (0-100%) |
Housing |
||
|
High tensile cast Aluminum, high temperature resistant/anti-UV ABS, IP66 |
|||
|
Effect Wheel |
|||
|
1 exchangeable graphic effect wheel, bi-directional rotation with varied speeds |
Ambient Temperature |
||
|
-20℃ ~ 45℃ |
|||
|
Focus |
Note: if the ambient temperature is below -20°C | ||
|
0-100% linearly adjustable by DMX |
please preheat the lamp more than 30 minutes and reset it again. |
||
|
|
|||
|
Dimmer |
Weight |
||
|
Linear dimmer 0-100% |
56Kg |
||
|
3 dimmer speeds |
|||
|
4 dimmer gamma curves |
Packaging |
||
|
Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera |
Standard: carton 855×655×815(mm) |
||
|
Optional: flight case 695x535x870(mm) |
|||
|
Iris |
|||
|
Linear iris 5-100% with macros |
Accessories |
||
|
G clamp 2 Pcs |
|||
|
Strobe |
XLR connector 1 Set Male and female |
||
|
Double shutter blades, 0.3~25 F.P.S |
Safety cord 2 Pc |
||
|
This manual 1 Pc |
|||
|
Head Movement |
Ω clamp 2 Pcs Optional |
||
|
Pan 540º, Tilt 270º with auto position correction |
Power Cord 1 Pc | ||
|
Beam Angle |
|||
|
Beam angle: 6°～ 56° Linear zoom with 16 bit precision |
|||
| CMY | |||
|
CMY linear coloring mixing system with macros |
|||
| Color Wheel | |||
|
1 Color Wheel：6 color + white |
|||
|
Bi-directional rainbow effect with variable speeds and half color effect |
|||
|
Linear /stepping color changing |
|||
|
|
|||
| Rotating Gobo | |||
|
1 rotating gobo wheel: 6 exchangeable+ white, glass or metal gobos |
|||
|
Bi-directional rotation, indexing, shake with varied speeds, bi-directional |
|||
| scrolling with varied speeds | |||
| Fixed Gobo | |||
|
1 fixed gobo wheel |
|||
|
7 exchangeable gobos+ white |
|||
|
Shake effect with varied speeds and bi-directional rotation with varied speeds |
|||
| Framing | |||
|
Continual rotation with graphics with different sizes and shapes |
|||
|
4 blades for complete curtain effect |
|||
