Input Voltages | Control | ||
100-240V AC, 50/60Hz | International DMX512, 5 pins(optional 3 pins) interface | ||
RDM control protocol, ART-Net protocol | |||
Power Consumption | Short mode 35 channels, standard mode 38 channels and extended mode 54 channels | ||
1100W@230V | Self-test mode | ||
Light Source | Other Functions | ||
730W, (8,000K, 20,000 hrs) | Adjustable pan & tilt speed | ||
LCD display screen | |||
Strobe | Fixture and lamp usage time display | ||
Double shutter blades, 0.3-25 F.P.S | Modular structure for easy maintenance | ||
DMX512 wireless receiver | |||
Dimmer | DMX512 wireless transmitter(optional) | ||
0-100% linearly dimming | |||
Physical | |||
CTO | Housing: cast aluminum and high temperature UV resistant ABS, IP65 | ||
Independent 0-100% linear CTO | Ambient temperature: maximum 45°C | ||
Prism | Weight | ||
One 4-facet prism, bi-directional rotation with variable speeds | Net weight: 57Kg | ||
Frost | Packaging | ||
One linear frost filter | Standard: carton 855x655x815(mm) | ||
Optional: flight case 695x535x870(mm) | |||
Effect | |||
1 Interchangeable graphic effect wheel, bi-directional rotation with variable speeds | Accessories | ||
G clamp, 2 pcs | |||
Iris | 5 Pins XLR connector, 1 set | ||
5-100% linearly adjusted with macros | Safety cord, 1 pc | ||
Power cord, 1 pc | |||
Focus/Zoom | Optional: Ω clamp, 2 pcs | ||
DMX linear focus/zoom | |||
Head Movement | |||
Pan 540°, tilt 270° with auto position correction | |||
Light Angle | |||
7°~60° | |||
| CMY | |||
CMY linear color mixing system with macros | |||
| Color Wheel | |||
1 Color wheel: 6 dichroic color filters plus open | |||
(optional: 5 interchangable color filters +1 high CRI filter plus open) | |||
Rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
| Fixed Gobo | |||
1 Fixed gobo wheel: 7 interchangeable gobos plus open | |||
Bi-directionally rotatable, and shakable effect at variable speeds | |||
| Rotating Gobo | |||
1 Rotating gobo wheel: 6 interchangeable gobos plus open | |||
Bi-directional rotation, indexing, shake with varied speeds | |||
Bi-directionally rotatable, and shakable at variable speeds | |||
| Framing | |||
4 Sets of framing blades | |||
Framing module endless rotation with many graphic of different sizes and shapes | |||
curtain effect | |||
