INPUT VOLTAGES | NOISE | ||
208V~240V AC，50/60Hz | Less than 45 dBA | ||
INPUT POWER | OTHER FUNCTION | ||
1800W@220V | Adjustable Pan & Tilt speed | ||
Power factor: PF>0.90 | Lamp and Total hours displayed | ||
Current@ Maximum 10A@187V | Color touch screen ,English and Chinese menus | ||
Display invertible and Auto fan speed control | |||
LIGHT SOURCE | Energy saving ballast | ||
OSRAM lok-it 1400/PS (6000K,CRI >95,single ended ,750hrs) | Built-in sensor diagnostic system | ||
Input signal isolation | |||
CTO | Modular Structure for easy maintenance | ||
0-100% linear CTO | DMX channel monitoring | ||
Magnet sensor positioning with signal feedback, absolute position memeroy | |||
ZOOM | Auto-positioning after DMX signal disruption or power off | ||
DMX linear zoom | Firmware upgrade via DMX | ||
DIMMER | |||
0-100% linear dimmer | HOUSING | ||
High temperature ABS, IP20 | |||
STROBE | |||
Double shutter blades, 0.3~25 F.P.S | NET WEIGHT | ||
44Kg | |||
HEAD MOVEMENT | |||
Pan 540º, Tilt 270º with auto position correction | Packaging | ||
Standard: carton 840x640x738(mm) | |||
BEAM ANGLE | Optional: flight case 720x580x900(mm) | ||
linear zoom 15°～ 60°with 16 bit function | |||
OPERATION TEMPERATURE | |||
CONTROL | Ambient temperature at maximum：40°C | ||
DMX512, 5 pin interfaces | |||
RDM and Art-Net controls with options for RJ45 interfaces | ACCESSORIES | ||
wireless DMX control and sCAN protocol | Clamps 2 Pcs | ||
19channels in short mode | XLR Connector 1 Set Male and female | ||
24channels in standard mode and 29channels in extended mode | Safety cord 2 Pc | ||
Self-test mode | User manual 1 Pc | ||
| CMY | |||
CMY linear mixing system with macros | |||
| Color Wheel | |||
2color wheels: 7colors+ Open, Half Color effect | |||
rainbow effect with bi-directional and variable speeds | |||
Stepping/linear color changing | |||
