| ELECTRICALPARAMETERS Input voltage: 100V-240VAC，50/60Hz Input power: 600W @ 100V 570W @ 220V Powerfactor: PF>0.9 SPECIFICATIONS OFLIGHTSOURCE PHILIPS ：MSD Platinum 300S Flex (380W) ColourTemperature ：7800K +/-300K ManufacturersRatedLampLife ：6000hrs （Reference the spec of MSD Platinum Flex 300S） PRISM/EFFECTWHEEL 3Prisms(standard 8facet prism+16facet prism+linear prism)(bi-directionalrotationwith variable speeds) + Frost+ Open (Optional 3-16 facet prismor gradient prism) FOCUS 0-100% linearly adjustable by DMX STROBE Double shutter blades, 0.3~20 F.P.S |
HEADMOVEMENT Pan 540º,Tilt 270º with auto position correction BEAMANGLE Beamangle 2° CONTROL InternationalstandardDMX512 signal and 5 pin interfaces 16channelsin shortmode, 20channelsin standardmode,21channel in extendedmode Adjustablemode OTHER FUNCTIONS AdjustablePan&Tiltspeed Fixture and lamp hours’display Modular construction for easymaintenance DMX512wirelessreceiver DMX512wirelesstransmitter(optional) HOUSING CastAluminum, high temperature resistant/anti-UVABS,IP66 WEIGHT 29 Kg |
| 【Version:20231110】 |
| 1 Color Wheel |
| 12Dichroic colour filters +Diffuser+ Open |
| Variable speed and bi-directional rainbow effect |
| Linear colour changing is available |
| 1 Fixed gobo wheel：16 static gobos+ white Shaking and bi-directional wheel scrolling at variable speeds 1Rotating gobo wheel: 12 gobos+ White Shaking and bi-directional wheel scrolling at variable speeds Gobo changeable |
